High Quality Waterproof Outdoor SMD HD P8 Led Display Screen For
Advertising,P8 SMD LED waterproof outdoor full color display
outdoor advertising led display P8 Smd,Waterproof Outdoor HD SMD
LED Video Display P8mm
Arise Technology Co., Ltd
One-stop LED display manufacturere
Web:http://www.ariseled.com
QQ:1327078259 Skype:ariseled
http://i.youku.com/ariseled
Product Model | P8 |
Module size | 256mm*128mm |
Pixel pitch | 8mm |
Pixel density | 15625dots/m2 |
Pixel configuration | 1R1G1B |
Module resolution | 32dots(W)*16dots |
Module maximum power consumption | 25W |
Module Thickness | 25CM |
Module Weight | 0.45kg |
Driving method | Constant Current Driving |
Scanning method | 1/4 scan |
Interface | HUB75 |
Brightness | 7500cd/m2 |
The specifications of cabinets |
Cabinet size | 1024mm*768mm |
Module quantity | 24pcs |
Power supply | 5V/40A 5V/60A |
Cabinet resolution | 128*96dots |
Optimal viewing distance | 8M~100M |
Optimal viewing angle | 140°(W) 120°(H) |
RHWorking temperature | (Work :-20°C~+55C) |
System operating humility | 10%-95% |
The specifications of power supplier |
Operating Voltage | AC220V±10% |
Average power consumption | 380W/H |
Maximum power consumption | ≤760W/m2 |
Electric current | ≤20mA(single LED) |
The specifications of control card |
Control Panels | Pentium4 or above |
Operating system | WIN98/2000/NT/XP |
Control model | Synchronization with PC |
The specifications of the main technical parameters |
Driving device | Constant Current Driving |
Refresh rate | 320-1000HZ |
Grey scale | RGB Each 256, can display 16.7M colors) |
MTBF | ≥10000hours |
Power switch | Automatic Switch |
Display Mode | 800*600/1024*768/1280*900 |
1.high temperature resistant and aging resistant PC materials are
applied in the modules to get rid of the mosaic problem even after
long time use.
2.High brightness enables longer viewing distance and ensures the
spectators far from the screen can still enjoy what is shown, even
under direct sunlight.
3.The cabinets, featuring great moisture and corrosion proofing,
enable themselves to work in all weather conditions.
Arise Technology Co., Ltd. is a high-tech company dedicated in
providing professional LED displays and comprehensive
optoelectronic solutions.
Arise Technology owns strong execution, brilliant development
strategies and programs, sustainable creation based on market
demand. We spare no effort to provide customers with
market-oriented innovative products with good reliability, suitable
solutions and all-round service. Our main products includes indoor
and outdoor full color fixed installation LED display, indoor and
outdoor rental LED displays, LED Mesh/LED curtain displays, LED
advertising player displays, floor LED displays, stadium/perimeter
LED displays, creative LED displays, mobile LED displays, flexible
LED displays, transparent LED displays, high-resolution full color
LED display, customized LED displays, and the whole display system
and equipment. We are ready to providing LED display solutions for
oversea and domestic advertisement media, building advertising and
lighting, municipal administration, hospital, hotel, bank, traffic,
sports, entertainment, show, exhibition, etc.
We Arise Technology regard integrity in company staff, customers
and suppliers as the enterprise foundations, market demands as the
guide. We guarantee quality with profession and dedication and use
enterprise culture to fill our brand. We keep striving, forging
ahead, creating to provide customer with strong and unremitting
support and backup.
We Arise Technology also have more LED displays for your projects:
Category Pixel Pitch(mm)
1. Outdoor Fix Installation LED Display Series P4/ P5/ P6/ P6.67/
P8/ P10 (DIP)/ P10 (SMD)/ P10.4/ P12/ P16
2. Outdoor Strip/Louver LED Display Series P15.625-15.625/
P15.625-31.25/ P31.25-31.25
3. Outdoor Rental LED display Series P3.9/ P4.8/ P5/ P6/ P6.25/
P6.67/ P6.94/ P7.8/ P8/ P8.9/ P10
4. Indoor Fix Installation LED display Series P1.2/P1.56/P1.6/
P1.667/ P1.8/ P1.875/ P1.9/ P2/ P2.5/ P3/
P3.9/ P4/ P4.8/ P5/ P6/ P6.67/ P7.62/ P8/ P10
5. Indoor Rental LED Display Series P2/ P2.5/ P3/ P3.125/ P3.75/
P3.91/ P4/ P4.81/ P5/ P6/
P6.25/ P6.4/ P7.62/ P8/ P10
6. Transparent LED Display Series P3.9-7.8/ P7.8-15.625/ P8/ P10
7. Floor LED Display Series P6.25/ P6.25 interactive floor LED
display /P8.9/ P10.4
8. Perimeter LED Display Series P6/ P8/ P10/ P12/ P16
9. LED Advertising Player/Kiosk LED Display Series P2.5/ P3/ P4/
P5/ P5.3/ P6
10. Taxi/Bus Mounted LED Display Series P4/ P5/ P6/ P7.62
11. LED Ball Display Series P3/ P4/ P5/ P6/ P7.62/ P8/ P10
12. Multiple creative LED displays and DJ booth LED displays for
clubs and stages.
• Stair LED displays: P6/ P6.67/ P7.62/ P10/ P16/ P18/ P20
• Led Street Screen: p4/p5/p6/p8
• LED Floor Tiles: P6.25/ P8.9/ P10.4
• Led Stage Screen-DJ screen: P3/ P4 /P5/ P6
• More customized LED displays.
